Sitecore database upgrade preparation

 Upgrade database
 Upgrade VS solution
 Upgrade docker files.

Prerequisites for upgrading

You should know your local host Windows ltsc version and your sitecore topology. For me, ltsc version was 2019 and sitecore topology was xp0.
Go to https://dev.sitecore.net/Downloads/Sitecore_Experience_Platform/103/Sitecore_Experience_Platform_103_Update1.aspx  and review the “Upgrade Container Deployment Guide”.
Download and extract the Sitecore Container Deployment package via the “Container Deployment Package” link present on https://dev.sitecore.net/Downloads/Sitecore_Experience_Platform/103/Sitecore_Experience_Platform_103_Update1.aspx  to a folder on your local, say C:/sitecoreupgrade.
Based on your ltsc version and topology, navigate to the corresponding folder and review its content.

In my case it was C:sitecoreupgradeSitecoreContainerDeployment.10.3.1.009452.1448composeltsc2019upgradexp1

As there was no folder for xp0, we decided to use the xp1 topology folder
We went with compose folder as we were using docker and not Kubernetes

Inside the xp1 folder, review contents of docker-compose.upgrade.yml to identify what all databases (see lines 7-16 in screenshot below) backups you need from prod.

Before taking the prod db backup, you can create/verify a login on prod sitecore that you can use to login to sitecore on local host to clean up databases and perform post upgrade steps.

Upgrade Preparation Steps

Take backups of existing 9.3.0 production databases on Azure.

These generally have bacpac extensions
We had saved the bacpac files in a Blob Container

Download and install “Microsoft Azure Storage Explorer”.
Open Azure storage explorer and connect to Blob Container via these steps

Navigate to “Storage Accounts” node in Azure Explorer and right click
Select “Connect to Azure Storage”
Select “Blob container or directory” as the Azure resource
Select your preferred connection method. As our DevOps team had shared the SAS URL of the Blob Container with me, I used that as the connection method. After connecting to Blob Container, download the bacpac files

On your local, start all the containers in your 9.3.0 solution.
Connect to SQL server instance present inside the SQL container using SSMS on your local host. SQL Server name generally has this syntax – “127.0.0.1,port number”. E.g. 127.0.0.1,1433
Take backups of existing 9.3.0 databases from local via SSMS.
Enable contained database authentication by running this following command in SSMS.
sp_configure ‘contained database authentication’, 1;
GO
RECONFIGURE;
GO

Import all the bacpac files from production on local host via “Import Data-tier Application” functionality in SSMS. You may append the text “.Prod” to new database name so that you can differentiate between prod and local version of databases. E.g. “Sitecore.Master.Prod”. See screenshots below for reference.

Note:- We observed that our SQL container volume was complaining about disk space at this location “C:Program FilesMicrosoft SQL ServerMSSQL14.MSSQLSERVERMSSQLDATA”. So we ended up changing that to “C:Data” for both Data file path and Log file path. The reason being the path “C:Program FilesMicrosoft SQL ServerMSSQL14.MSSQLSERVERMSSQLDATA” was inside the container and had limited space. Hence changing it to “C:Data” (which maps back to my local host via volume mount as mentioned in steps below) made it use my local host disk space.

Stop the SQL container via this command “docker stop <sqlcontainername>” E.g. docker stop my_container
Review the “sql” service section of your solution’s docker-compose file and observe the local host path set under volume. In my case it was datasql folder(see line #7 in screenshot below) inside the docker folder of the solution.
sql:
image: ${REGISTRY}sitecore-xp-sxa-sqldev:${SITECORE_VERSION}-windowsservercore-${WINDOWSSERVERCORE_VERSION}
isolation: ${ISOLATION}
restart: ${RESTART_POLICY:-unless-stopped}
hostname: ${SQL_HOST}
volumes:
– .datasql:C:Data
networks:
default:
aliases:
– ${SQL_HOST}
mem_limit: 2GB
ports:
– “1433:1433”
environment:
SA_PASSWORD: ${SQL_SA_PASSWORD}
ACCEPT_EULA: “Y”
SQL_HOSTNAME: ${SQL_HOST}
# Allows for access to the database through traefik to support using database locally.
# This should not be used in production.
#
# Since this is not http, but tcp traffic it does does not understand the concept of a “host”.
# so we must dedicate a port to it in traefik, and direct all traffic to this router: HostSNI(`*`).
labels:
– “traefik.enable=true”
– “traefik.tcp.routers.${COMPOSE_PROJECT_NAME}-sql.entrypoints=sql”
– “traefik.tcp.routers.${COMPOSE_PROJECT_NAME}-sql.rule=HostSNI(`*`)”
– “traefik.tcp.routers.${COMPOSE_PROJECT_NAME}-sql.service=${COMPOSE_PROJECT_NAME}-sql”
## Service for SQL requests
– “traefik.tcp.services.${COMPOSE_PROJECT_NAME}-sql.loadbalancer.server.port=1433”

Go to the folder dockersqldata in your solution and

Observe the names of the local 9.3.0 data and log files. Eg Sitecore.Master, Sitecore.Core etc.
Move all the mdf and ldf files related to the production databases you imported in the steps above to a different folder say C:sitecoreupgradeproddbs
Rename the files in “C:sitecoreupgradeproddbs” folder to match the file names of local 9.3.0 files. E.g Rename “Sitecore.Master.Prod” to “Sitecore.Master”
Copy the files from “C:sitecoreupgradeproddbs” to “dockersqldata” folder of your solution and replace the existing files

Restart the sql container via this command ” docker start <sqlcontainername>”. Note:- the sitecore instance might take a few minutes to come up when you restart SQL container. Till then it might show SQL timeout error.
Build your VS solution.
Delete the databases having “.Prod” in their names to free up disk space.(Optional)
At this point, your local site is using 9.3.0 code base from local and production version of 9.3.0 databases. If you have a production sitecore login, then you can try to login to your local sitecore instance using that to verify that you are seeing the production content.
Connect again to SQL container via SSMS and create a new login say “sitecoreupgrade” and give it “db owner” membership role for all the sitecore databases.
